Brand Name: | UCER |
Model Number: | UH-5075 Series |
MOQ: | 1000 Meters |
Price: | $19.8/ Meter |
Delivery Time: | 45 work days |
Payment Terms: | L/C, T/T, D/P, CAD |
Hanging Conveyor Chain (UH-5075 Series) Spray Coating Line Trolley Steel Driving Overhead Conveyor Chain
Quick Detail
Applicable Industries:Machinery Repair Shops, Food & Beverage Factory, Restaurant, Home Use, Food Shop, Printing Shops
Standard or Nonstandard:Nonstandard
Type:hanging conveyor chain
Material:ALLOY, Carbon steel
Tensile Strength:20-50% Higher
Place of Origin:Zhejiang, China
Brand Name:UCER
Load Capacity:5 tones
chain's weight:4.2-6.58KG
Chain's catastrophic pull force:5500KG
Chain's allowable pull force:3500KG
Working temprature:<=250 ℃
Moving Speed:0-12meter/min
usage:workshops continual conveying
Suspension Spacing:150+(150*N) mm
Dimension(L*W*H):152*52*75mm
Specification
ODEL ITEM |
UH-5075-S Standard chain |
UH-5075-HH Heavy-duty chain
|
UH-5075-HV Heavy-duty chain |
UH-5075-HA Heavy-duty chain |
Suspension Spacing (mm) |
150+(150× N) | 150+(150 × N) | 150+(150 × N) | 150+(150 × N) |
Chain's Weight (kg/m) |
4.2 | 4.58 | 4.83 | 5.3 |
Single-span Weight (≤kg) |
35 | 40 | 45 | 50 |
Chain's Allowed Pull Force (≤kgf) |
3000 | 3000 | 3000 | 3000 |
Chain's Catastrophic Pull Force (≥kgf) |
5500 | 5500 | 5500 | 5500 |
Working temperature (≤°C) |
250 | 300 | 300 | 400 |
Applicable Equipment | General conditions |
Large bending; High temperature; |
High temperature; Heavy work piece; Frequently lifted; |
High temperature; Heavy work piece; Complicated route; |
Material | 16# Medium-carbon steel, Steel A3 | |||
Remark: The above technical data is for our usual over head conveyor chain: UH-5S, UH-5HH, VH-5HA type. We can customize design and manufacture the products based customers particular requirements |
Packing Delivery Shipping
Packaging Details:
Packing: The chain conveyor will be packed in standard export carton, like fiber bag, also can be packed as your requirement.
Port: shanghai ,ningbo
Delivery Details:
Recommend Products
Our Service
1. UCER chain supply OEM/ODM service.
2. We have been producing all kinds of standard chains and special chain: Driving Chain, Agriculture Chain, Conveyor Chain, Long Pitch Conveyor Chain, Stainless Steel Chain, Hoisting Chain, Motorcycle Chain, Dropped Forged Rivetless Chain and so on.
