Heavy Duty Conveyor Chain
Created with Pixso. C2060 C2080 Double Pitch Conveyor Chains With Extended Pins

C2060 C2080 Double Pitch Conveyor Chains With Extended Pins

Brand Name: UCER
Model Number: C2060 C2080
MOQ: 50 Meters
Price: $2.00 - $50.00/ Meter
Delivery Time: 45 work days
Payment Terms: L/C, T/T, D/P, CAD
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001
Product Name:
Double Pitch Conveyor Chains With Extended Pins
Structure:
Roller Chain
Roller Chain Name:
Doube Pitch Conveyor Chains And Extended Pins
Material:
40Cr C45
Function:
Conveyor Chain
Color:
Black & Gray
Standard Or Nonstandard:
Nonstandard
Conveyor Chain Name:
Chain With Extended Pin
Packaging Details:
a conveyor chain with extended pin + a poly bag + individual box + a wooden case
Supply Ability:
10000 Meters per Month
Highlight:

C2080 Double Pitch Conveyor Chains

,

C2060 Double Pitch Conveyor Chains

,

C45 roller chain with extended pins

Product Description

Double Pitch Conveyor Chains With Extended Pins Heavy Duty Conveyor Chains





Quick Details:

Finish:Black, Plain

Place of Origin:Zhejiang, China

Brand Name:UCER

Model Number:C2052

Structure:Roller Chain

Function:Conveyor Chain

Standard or Nonstandard:Nonstandard

roller chain name:doube pitch conveyor chains and extended pins

conveyor chain type:chain with extended pin

OEM service:accept

Color:black & gray

delivery time:on time

production maker:China manufacturer

material:alloy steel or stainless steel

marerial:40Cr C45

heat treatment:all the chain parts with heat treatment

size&capacity:pls reference to the form

Supply Ability:10000 Meter/Meters per Month





Specification





C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 0

C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 1

DIN ISO Chain No. ANSI Chain No. Pich G L C1 C2 F d4 d5
mm inch mm
C208A C2040 25.4 1" 19.1 9.5 11.1 13.5 20.5 3.4 5.5
C210A C2050 31.75 1"1/4 23.8 11.9 14.3 15.9 25 5.5 6.6
C212A C2060 38.1 1"1/2 28.6 14.3 17.5 19.1 32.9 5.5 9.2
C216A C2080 50.8 2" 38.1 19.1 22.2 25.4 43.5 6.6 11
C220A C2100 63.5 2"1/2 47.6 23.8 28.6 31.8 50.4 8.4 13





C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 2

DIN ISO Chain No. ANSI Chain No. Pich G L F W h d4
mm inch mm
C208A C2040 25.4 1" 19.1 9.5 25.4 39.6 9.1 3.4
C210A C2050 31.75 1"1/4 23.8 11.9 31.8 49 11.1 5.5
C212A C2060 38.1 1"1/2 28.6 14.3 42.8 67.8 14.7 5.5
C216A C2080 50.8 2" 38.1 19.1 55.6 87.8 19.1 6.8



C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 3

DIN ISO Chain No. ANSI Chain No. Pich G L C1 C2 F d4 d5
mm inch mm
C208A C2040 25.4 1" 19.1 9.5 11.1 13.5 20.5 3.4 5.5
C210A C2050 31.75 1"1/4 23.8 11.9 14.3 15.9 25 5.5 6.6
C212A C2060 38.1 1"1/2 28.6 14.3 17.5 19.1 32.9 5.5 9.2
C216A C2080 50.8 2" 38.1 19.1 22.2 25.4 43.5 6.6 11



C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 4

DIN ISO Chain No. ANSI Chain No. Pich b1 d2 L3 L Lc
mm inch mm
C208A C2040 25.4 1" 7.85 3.96 9.5 25.1 26.2
C210A C2050 31.75 1"1/4 9.4 5.08 11.9 31.3 33.1
C212A C2060 38.1 1"1/2 12.57 5.94 14.3 38.6 40.6
C216A C2080 50.8 2" 15.75 7.92 19.1 50.3 53.3
C216AH C2080H 53.5 55
C216AHL C2082H 53.5 55
C220A C2100 63.5 2"1/2 18.9 9.53 23.8 61.8 66.1
C220AL C2102 61.8 66.1
C220AH C2100H 65 68.3
C220AHL C2102H 65 68.3
C224AH C2120H 76.2 3" 25.22 11.1 28.6 79.6 83.6
C224AHL C2122H 79.6 83.6
C232AH C2160H 101.6 4" 31.75 14.27 38.1 103 107.8
C232AHL C2162H 103 107.8



C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 5



DIN ISO Chain No. ANSI Chain No. Pich b1 d2 L3 L Lc
mm inch mm
C208A C2040 25.4 1" 7.85 3.96 4.1 16.6 18.8
C208AL C2042 25.4 1" 7.85 3.96 4.1 16.6 18.8
C210A C2050 31.75 1"1/4 9.4 5.08 5.1 20.7 23.3
C210AL C2052 31.75 1"1/4 9.4 5.08 5.1 20.7 23.3
C212A C2060 38.1 1"1/2 12.57 5.94 6.1 25.9 28.3
C212AL C2060 38.1 1"1/2 12.57 5.94 6.1 25.9 28.3
C212AH C2060H 38.1 1"1/2 12.57 5.94 6.1 29.2 31.6
C212AHL C2062H 38.1 1"1/2 12.57 5.94 6.1 29.2 31.6
C216A C2080 50.8 2" 15.75 7.92 8.1 32.7 36.5
C216AL C2082 50.8 2" 15.75 7.92 8.1 32.7 36.5
C216AH C2080H 50.8 2"1/2 15.75 7.92 8.1 36.2 39.4
C216AHL C2082H 50.8 2"1/2 15.75 7.92 8.1 36.2 39.4
C220A C2100 63.5 2"1/2 18.9 9.53 10.1 40.4 44.7
C220AL C2102 63.5 2"1/2 18.9 9.53 10.1 40.4 44.7
C220AH C2100H 63.5 2"1/2 18.9 9.53 10.1 43.6 46.9
C220AHL C2102H 63.5 2"1/2 18.9 9.53 10.1 43.6 46.9





C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 6

DIN ISO Chain No. Pich b1 d2 d3 d5 L3
mm inch mm
C2052 31.75 1"1/4 9.4 5.08 6 11 30
C2060H 38.1 1"1/2 12.57 5.94 7.92 12.7 41.91





Packing Delivery Shipping



Packaging Details:

Packing: a conveyor chain with extended pin + a poly bag + individual box + a wooden case

Port: shanghai ,ningbo

C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 7

Delivery Details:

Usually, we pack conveyer chain in polybag and box. then put the box in the creat. we offer yellow or white box for free, which marked length and size only, customer also may offer his box sample to us. our crate dimension: 100×75×75cm(800Kg could be packed)or 105×95×75cm(1000Kg could be packed); Usually 20' container could pack about 20-25 ton, but it depend on the requirement of the customs of every country. Packed chain on the pallet directly also optional.





Recommend Products

C2060 C2080 Double Pitch Conveyor Chains With Extended Pins 8





Our Service



1. UCER chain supply OEM/ODM service.

2. We have been producing all kinds of standard chains and special chain: Driving Chain, Agriculture Chain, Conveyor Chain, Long Pitch Conveyor Chain, Stainless Steel Chain, Hoisting Chain, Motorcycle Chain, Dropped Forged Rivetless Chain and so on.
