1) The belt has good elasticity, impact resistance and abrasion resistance.
2) Good flexibility, easy to form grooves.
3) No mildew occurs.
National Standard GB/T7984-2001
Nylon (NN) conveyor belt:
Covering layer: the tensile strength is not less than 15Mpa, the elongation at break is not less than 350%, the amount of wear is less than or equal to 200mm3.
The average value of the interlayer adhesion strength of the longitudinal sample is not less than 4.5 N/mm between the cloth layers, and not less than 3.2 N/mm between the cover rubber and the cloth layers.
The full thickness longitudinal elongation at break is not less than 10%, and the full thickness longitudinal reference elongation is not greater than 4%
Adhesive strength between layers of nylon conveyor belt:
Between cover layer and cloth layer
Covering layer thickness ≤1.5mm
Covering layer thickness>1.5mm
The average value of the longitudinal sample is not less than
The average value of the transverse sample is not less than
The highest peak value of all samples is not greater than
The lowest peak value of all samples is not less than
