Rubber Conveyor Belts
Created with Pixso. Bandwidth 100mm-2200mm 3 Ply Rubber Conveyor Belt

Bandwidth 100mm-2200mm 3 Ply Rubber Conveyor Belt

Brand Name: UCER
Model Number: EP100/EP150/EP200/EP250/EP300
MOQ: 100 meters
Price: Negotiable
Delivery Time: 10-30 days
Payment Terms: L/C, D/P, T/T
Detail Information
Place of Origin:
China
Certification:
Enterprise credit rating AAA
Color:
White
Bandwidth:
200mm
Model:
NN150
Structure:
Belt Conveyor
Conveyor Belt Layer:
3-12 Layers, 3 Layers
Material:
Cover Rubber, NN, EP
Tensile Strength:
Not Less Than 15Mpa
Cloth Layer:
Not Less Than 2.1 N/mm
Packaging Details:
Iron packing, iron frame or other
Supply Ability:
10000 per month
Highlight:

Bandwidth 2200mm 3 Ply Rubber Conveyor Belt

,

Bandwidth 2200mm Rubber Conveyor Belt

,

Bandwidth 100mm Rubber Conveyor Belt

Product Description

Bandwidth 100mm-2200mm 3 Ply Rubber Conveyor Belt



1. Specifications and models


According to the different use environment and requirements, it is divided into many specifications and models:

1) According to the customer, it can be cut at will according to the width;
2) According to the different use environments, it is divided into ordinary conveyor belts and includes (ordinary type, heat-resistant type, flame-retardant type, burn-resistant type, acid-base resistant type, oil-resistant type), heat-resistant conveyor belt, cold-resistant conveyor belt, and Acid-base conveyor belt, oil-resistant conveyor belt, food conveyor belt and other models. Among them, the minimum thickness of cover rubber on ordinary conveyor belts and food conveyor belts is 3.0mm, and the minimum thickness of lower cover rubber is 1.5mm; the minimum thickness of cover rubber on heat-resistant conveyor belts, cold-resistant conveyor belts, acid and alkali resistant conveyor belts, and oil-resistant conveyor belts is 4.5 mm, the lower cover rubber should be at least 2.0mm. According to the specific conditions of the use environment, the thickness of the upper and lower cover rubber can be increased by 1.5mm;
3) According to the tensile strength of the conveyor belt cloth layer, it is divided into ordinary conveyor belt white rubber conveyor belt and powerful conveyor belt. Powerful canvas conveyor belts are divided into nylon conveyor belts (NN conveyor belts) and polyester conveyor belts (EP conveyor belts).

Supplementary note: The strong layer of the strong conveyor belt is polyester canvas (EP), which is divided into EP100, EP150, EP200, EP250, EP300, EP350, EP400, etc.; it can also be nylon canvas (NN) , Can be divided into NN100, NN150, NN200, NN250, NN300, NN350, NN400, NN450, NN500, etc.



2. Variety:

According to the different properties of the covering rubber, it can be divided into ordinary type, heat-resistant type, flame-retardant type, cold-resistant type, acid-base resistant type, oil-resistant type, etc.

<

Variety Standards and main indicators
Ordinary steel cord conveyor belt GB/T9770-2001
Flame-retardant steel cord conveyor belt MT668-1997
General flame-retardant steel cord conveyor belt MT668-1997
Heat-resistant steel cord conveyor belt HG2297-92
Wear-resistant steel cord conveyor belt Shaoboer wear amount ≤90mm 3
Acid, alkali and oil resistant steel cord conveyor belt HG4-846
HG4-846
Cold-resistant steel cord conveyor belt Brittleness temperature -40℃







Bandwidth 100mm-2200mm 3 Ply Rubber Conveyor Belt 0
