8000mm Length ST630 Special Conveyor Belts For Metallurgy

Brand Name: UCER
Model Number: ST630/ST800/ST1000/ST1250/ST1600/ST2000
MOQ: 100 meters
Price: Negotiable
Delivery Time: 10-30 days
Payment Terms: L/C, D/P, T/T
Detail Information
Place of Origin:
China
Certification:
Enterprise credit rating AAA
Color:
Black
Width:
800mm
Length:
8000mm
Standard Or Nonstandard:
Standard
Model:
ST630
Thickness:
6mm-30mm
Usage:
Conveyor
Warranty:
1 Year
Packaging Details:
Iron packing, iron frame or other
Supply Ability:
10000 per month
Highlight:

ST630 Special Conveyor Belts

,

Special Conveyor Belts For Metallurgy

,

High temperature resistant conveyor belt ST630

Product Description

High temperature resistant conveyor belt ST630 Special Conveyor Belts



High temperature resistant conveyor belt is a conveyor belt used to transport high temperature materials.



1. Classification


Heat-resistant conveyor belts are divided into ordinary heat-resistant belts and strong heat-resistant conveyor belts. The strength layer of ordinary heat-resistant belts is polyester cotton canvas (CC56), and the strength layer of strong heat-resistant belts is EP (specifically, it is divided into EP100 and EP150. EP200, EP250, EP300, EP350, EP400, EP450, EP500, etc.).



2. Purpose


It is mainly used in metallurgy, construction and other industries to transport high-temperature materials such as sinter, coke, cement clinker, etc. The material temperature does not exceed 800℃, and the belt surface temperature does not exceed 220℃. Features: Use EPDM rubber as the covering layer, and use domestic special high-temperature resistant canvas as the skeleton material. The unique formula design solves the key problems of high saturation of ethylene propylene rubber, poor adhesion, and low interlayer adhesion. . It has the characteristics of light belt body, long life (about 2-4 times) and good heat resistance.
The implementation of the "Conveyor Belt with Rubber or Plastic Covering Layer of General Purpose Fabric Core Conveyor Belt" standard, this standard adopts the draft international standard ISO/FDIS14890-1999 standard
The heat-resistant conveyor belt is made of multi-layer rubber cotton canvas (poly-cotton cloth) or polyester canvas covered with high-temperature or heat-resistant rubber and bonded together by high-temperature vulcanization. It is suitable for conveying hot coke, cement, and slag below 175°C. And hot castings, etc.
1) The specifications are the same as ordinary conveyor belts.
2) The product implements the HG2297-92 standard.
3). Heat-resistant conveyor belts can be divided into four types:
Type I: It can withstand test temperature not greater than 100℃, the highest short-time operating temperature is 150℃, code T1.
Type Ⅱ: It can withstand the test temperature of not more than 125℃, the maximum short-time operating temperature is 170℃, and the code is T2.
Type Ⅲ: It can withstand the test temperature of not more than 150℃, the highest short-time operating temperature is 200℃, and the code is T3.
Type IV: Can withstand test temperature not greater than 175℃, maximum short-time operating temperature 250℃, code T4.



<

Variety Standards and main indicators
Ordinary steel cord conveyor belt GB/T9770-2001
Flame-retardant steel cord conveyor belt MT668-1997
General flame-retardant steel cord conveyor belt MT668-1997
Heat-resistant steel cord conveyor belt HG2297-92
Wear-resistant steel cord conveyor belt Shaoboer wear amount ≤90mm 3
Acid, alkali and oil resistant steel cord conveyor belt HG4-846
HG4-846
Cold-resistant steel cord conveyor belt Brittleness temperature -40℃
